Flow Rate

54 CFM

Max Pressure

250 PSI

Rotation

360°

Hose Size

3/8"

01 — Rotation

360° Unrestricted Swivel

Precision ball-bearing swivel mechanism allows full, unrestricted rotation in any direction. As your tool moves, the hose follows — no fighting, no kinking, no pressure loss. Extends hose service life by eliminating the stress concentration that causes premature failure at the coupling end.

02 — Airflow

High-Flow Internal Architecture

Optimised 5mm nominal bore geometry delivers 54 CFM at 100 PSI — sufficient for the most demanding pneumatic tools. Smooth internal transitions minimise turbulence and pressure drop, so your tools receive the full rated airflow rather than a throttled approximation of it.

03 — Construction

Hardened Steel — Built for Industry

Manufactured from hardened steel with a corrosion-resistant finish. Rated to 17 bar (250 PSI) with a 4:1 safety factor. Resists impact, vibration, and chemical exposure in automotive, fabrication, and manufacturing environments where lesser fittings fail within months.

04 — Connection

Secure 9.5mm (3/8") Barbed Hose Tail

Precision-machined serrated barb profile creates a mechanical grip that resists blow-off under peak pressure cycling. No thread sealant required. Secure with a standard hose clamp or crimp ferrule for a leak-free connection that holds under sustained high-demand operation.

05 — Temperature Range

−20°C to +80°C Operating Range

Maintains full seal integrity and swivel function from unheated winter workshops to high-temperature industrial environments. Seals are formulated to resist compression set across the full operating range — no seasonal re-torquing, no cold-weather leaks.

↑ 300%

Hose Service Life

Eliminating twist stress at the coupling end dramatically reduces fatigue cracking and blow-off failures.

0 PSI

Pressure Drop Added

High-flow bore geometry ensures the swivel adds no measurable restriction to your air system.

360°

Freedom of Movement

Work around vehicles, machinery, and tight spaces without repositioning your hose reel.

↓ Risk

Trip Hazard Reduction

Hoses lie flat and follow the operator naturally — no coiled tangles accumulating on the workshop floor.

Automotive

Impact wrenches, ratchets, die grinders, HVLP spray guns, tyre inflators, and pneumatic lifts in busy MOT and bodyshop environments.

Industrial Fabrication

Sanders, angle grinders, cut-off tools, pneumatic hammers, and riveting equipment in steel fabrication and metalworking shops.

Paint & Finishing

HVLP and conventional spray guns, detail guns, blow-off guns, and air-fed respirator systems in professional paint booths.

Construction

Framing nailers, finish nailers, staplers, concrete vibrators, and portable compressor-fed tools on active construction sites.

Manufacturing

Assembly tools, pneumatic presses, material conveyance systems, and production line equipment requiring reliable continuous-duty air supply.

Fleet Maintenance

HGV, bus, and plant equipment servicing where high-torque pneumatic tools operate continuously across multiple bays.

Installation — 60 Seconds

Slide the 9.5mm barbed tail into your 3/8" pneumatic hose. Secure with a hose clamp or crimp ferrule. Connect the swivel body to your InstantAir quick-connect coupling. No PTFE tape, no thread sealant, no specialist tools required.

System Compatibility

Designed for the InstantAir quick-connect system. Compatible with all standard 3/8" pneumatic hose. Integrates into existing air line infrastructure without modification. Suitable for compressed air, inert gases, and dry nitrogen.

Maintenance Schedule

Inspect swivel rotation and check for wear or damage at each service interval. Clean external surfaces to prevent contamination ingress. Apply one drop of pneumatic tool oil to the swivel bearing annually in high-cycle applications.
